| Product Attributes |
Attribute Value |
| Category |
RF and Wireless |
| Manufacturer |
KYOCERA AVX |
| Package |
Bag |
| Description |
788.5MHz, 1.8GHz, 2.45GHz, 2.495GHz, 4.15GHz, 5.375GHz 802.11a/b/g/n/ac, IoT, LoRa, LTE, M2M, Sigfox, Wi-Fi, Zigbee™ Flat Patch RF Antenna 617MHz ~ 960MHz, 1.4GHz, 2.2GHz, 2.3GHz, 2.69ghz, 2.4GHz ~ 2.5GHz, 3.3GHz ~ 5GHz, 4.9GHz ~ 5.85GHz 3.1dBi, 2.7dBi, 2.2dBi, 2.2dBi, 2.3dBi, 1.3dBi SMA Male Adhesive |
| Features | Cable - 600mm |
| Mounting Type | Adhesive |
| Frequency Range | 617MHz ~ 960MHz, 1.4GHz, 2.2GHz, 2.3GHz, 2.69ghz, 2.4GHz ~ 2.5GHz, 3.3GHz ~ 5GHz, 4.9GHz ~ 5.85GHz |
| Applications | 802.11a/b/g/n/ac, IoT, LoRa, LTE, M2M, Sigfox, Wi-Fi, Zigbee™ |
| Gain | 3.1dBi, 2.7dBi, 2.2dBi, 2.2dBi, 2.3dBi, 1.3dBi |
| Termination | SMA Male |
| Number of Bands | 6 |
| VSWR | 2.2, 2.5 |
| Antenna Type | Flat Patch |
| Height (Max) | 0.008" (0.20mm) |
| Frequency Group | Wide Band |
| Frequency (Center/Band) | 788.5MHz, 1.8GHz, 2.45GHz, 2.495GHz, 4.15GHz, 5.375GHz |
| RF Family/Standard | Cellular, WiFi |
