| Product Attributes |
Attribute Value |
| Category |
RF and Wireless |
| Manufacturer |
Taoglas |
| Package |
Bulk |
| Description |
657.5MHz, 761MHz, 892MHz, 1.4725GHz, 1.575GHz, 1.795GHz, 2.045GHz, 2.495GHz, 4.15GHz, 5.5375GHz 2G, 3G, 4G, 5G, Cat-M, DCS, GPS, GSM, IoT, LTE, NB-IoT, NR, UMTS Whip, Tilt RF Antenna 617MHz ~ 698MHz, 698MHz ~ 824MHz, 824MHz ~ 960MHz, 1.427GHz ~ 1.518GHz, 1.563GHz ~ 1.587GHz, 1.71GHz ~ 1.88GHz, 1.92GHz ~ 2.17GHz, 2.3GHz ~ 2.69GHz, 3.3GHz ~ 5GHz, 5.15GHz ~ 5.925GHz -0.68dBi, -2.14dBi, 0.15dBi, -0.74dBi, -0.59dBi, 1.37dBi, 0.93dBi, 0.73dBi, 1.51dBi, 1.73dBi SMA Male Connector Mount |
| Mounting Type | Connector Mount |
| Frequency Range | 617MHz ~ 698MHz, 698MHz ~ 824MHz, 824MHz ~ 960MHz, 1.427GHz ~ 1.518GHz, 1.563GHz ~ 1.587GHz, 1.71GHz ~ 1.88GHz, 1.92GHz ~ 2.17GHz, 2.3GHz ~ 2.69GHz, 3.3GHz ~ 5GHz, 5.15GHz ~ 5.925GHz |
| Applications | 2G, 3G, 4G, 5G, Cat-M, DCS, GPS, GSM, IoT, LTE, NB-IoT, NR, UMTS |
| Gain | -0.68dBi, -2.14dBi, 0.15dBi, -0.74dBi, -0.59dBi, 1.37dBi, 0.93dBi, 0.73dBi, 1.51dBi, 1.73dBi |
| Termination | SMA Male |
| Ingress Protection | IP66 |
| Number of Bands | 10 |
| Antenna Type | Whip, Tilt |
| Height (Max) | 6.772" (172.00mm) |
| Frequency Group | Wide Band |
| Frequency (Center/Band) | 657.5MHz, 761MHz, 892MHz, 1.4725GHz, 1.575GHz, 1.795GHz, 2.045GHz, 2.495GHz, 4.15GHz, 5.5375GHz |
| RF Family/Standard | Cellular, Navigation |
| Power - Max | 2 W |
