Home / Products / Power Supplies - Board Mount / DC DC Converters / UCC14241QDWNRQ1

Same model may have multiple batches, images only for reference.

UCC14241QDWNRQ1
Manufacturer No: UCC14241QDWNRQ1
Manufacturer: Texas Instruments
SUVSysrem No: UCC14241QDWNRQ1
Package: Tape & Reel (TR)
Datasheet: UCC14241QDWNRQ1
Description: Isolated Module DC DC Converter 1 Output 15 ~ 25V 80mA 21V - 27V Input
Request Free Samples
  • ESD

    ESD

  • ISO9001

    ISO9001

  • ISO13485

    ISO13485

  • ISO14001

    ISO14001

  • ISO45001

    ISO45001

UCC14241QDWNRQ1 information
Product Attributes Attribute Value
Category Power Supplies - Board Mount
Manufacturer Texas Instruments
Package Tape & Reel (TR)
Description Isolated Module DC DC Converter 1 Output 15 ~ 25V 80mA 21V - 27V Input
FeaturesAdjustable Output
Package / Case36-BSSOP (0.295", 7.50mm Width)
Size / Dimension0.51" L x 0.30" W x 0.13" H (12.8mm x 7.5mm x 3.4mm)
Mounting TypeSurface Mount
TypeIsolated Module
Operating Temperature-40°C ~ 125°C
ApplicationsITE (Commercial)
Voltage - Input (Max)27V
Current - Output (Max)80mA
Supplier Device Package36-SSOP
Voltage - Input (Min)21V
Voltage - Output 115 ~ 25V
Control FeaturesEnable, Active Low
Power (Watts)2 W
Number of Outputs1
Voltage - Isolation5 kV
Standard Number62368-1
Package

  • Step1:
    Product

  • Step2:
    Casing drivepipe

  • Step3:
    Anti-static bag

  • Step4:
    Packging boxes

  • Step5:
    bar-code shipping tag
Returning/Warranty
SUV System provides a 365-day after-sales warranty period for all products, please feel free to contact us if you have any questions during this period.
